Parameter/Model

ModelL7518—4

ModelL7518—5

Maximum Temperature

1800℃

Working Temperature

1750℃

Maximum Effective Volume

Φ44×174mm

Φ70×270mm

Heat Preservation Time

30min

Power Supply

380V/220V　50Hz　15KW

380V/220V　50Hz　20KW

Hydrogen Pressure

1×10⁴～3×10⁴Pa Hydrogen consumption＜10L/min

Nitrogen Pressure

1×10⁴～5×10⁴Pa Nitrogen consumption ＜10L/min

Water Pressure

0.2～0.4Mpa Water consumption＜1T/h

Control Model

Manual and automatic

Overall Dimensions

900×750×1770mm

1000×1000×1600mm

Parameter/model

Model L1120Ⅱ

Maximum temperature

2000℃

Working temperature

1900℃

Maximum effective volume

35×15×150mm

Heating power

25KW

Power supply

220V/380V　50Hz  30KW

Hydrogen pressure

1×10³～3×10³Pa

Nitrogen pressure

1×10³～5×10³Pa

Water pressure

0.2～0.3Mpa

Control mode

Manual and automatic

Infrared measurement

800℃-2000℃ Under the temperature of 800℃,
the temperature is measured by labor.

Overall dimensions

820×1220×1600mm
